16.5''*47''(42cm*120cm) A2 ED4210T DTG Garment Printer(DX5 Printhead)

Model WER-ED4210T
Max Printing size 16.5*39.37‘ (420*1000mm) capable for three pc of t-shirts
No. of print head 2* DX5
Photo quality 5760*2880dpi
Accepted medie height 18cm max.
Ink type Water based ink for T-shirt direct printing
Ink channel 8 color (4-CMYK, 4 White) 180 nozzles/ color. Optional dual CMYK.
Printing interface USB 2.0 high speed interface & 100 Base-T Ethernet interface
Printing direction Smart Bi-directional Printing Mode
Printing speed  4 pass 120 seconds/A4 size
6 pass 160 seconds/A4 size
8 pass 200 seconds/A4 size
12pass 240 seconds/A4 size
Interface Double USB port
Languages English, Chinese.
Application Materials: cotton t-shirt, fabric, polyester
Printing method Drop on Demand (non-contact micro piezoelectric ink-jet printing technology; micro piezoelectric printing technology; VSDT; intelligent nozzle clogging sensor system). 180nozzle/color*8; VSDT
Production capacity 400pcs t-shirt/8 hours
White ink printing for black t-shirt T-shirt RIP for better printing
Auto adjustment function Nozzle automatic detection; print head automatic aligning.
Height adjustment Auto Sensor
Normal working environment Temperature 10-35Celsius Humidity 20-80RH
Power/ Voltage Ac220V   50/60Hz
Operational software Compatible
Machine configuration USB line; driving software; power line; instruction book; washing and ink-joiner tools
Operation system Windows 2000 / XP / WIN7/ Vista, etc.
Media feeding system Auto or Manual
Special remarks Customized service is available.



 Product Details




DX5 Printhead

Instruction: DX5, Resolution: 1440DPI
Color: 4 colors
Print mode: 4, 6, 8, 12 Pass

Notes:
A: Operators need to make antistatic treatment, please wear the Anti-static devices if permission, to prevent the high static load from burning the circuit board inside printhead
B: During installation, try not to directly touch the surface of printhead









Mainboard

Instruction: The mainboard and adapter board for controlling the printing of dual DX5 print heads

Notes:
A: Please connect the Ground Circuitry when installation
B: Please turn off power first, then plug or pull out connector of wire








Cartridges

Introduction: 440ml single color cartridge

Notice: Turn on the air hole when printing
           Please do not mix different color ink for printing




DX5 headboard

Instruction: Printhead board
Optical input
Designed with individual adapter board for disassembling easily, reduce cost on repair,and more convenience on changing it


Notes:
A: Please connect the Ground Circuitry when installation
B: Please turn off power first, then plug or pull out connector of wire







Screen panel

Introduction: Contain some control button, like control the movement of X axis, Y axis and Z axis

Notes: A. Do not touch the surface with sharp items
          B. Please take care of the screen when operating




  Printed Samples





 Excellent After-sale Services:



1.One year warranty

You can discuss operation and maintenance with our technician online support service by Skype, MSN etc. Remote control will be provided upon request.

2. Free exchange of new components

Our quality is guaranteed 100%, the spare parts can be replaced within one year free of charge includes the airfreight by express, except for the print head and some consumable parts.

3. Free online consultation

The technician will keep online. No matter what kind of technical questions that you may have, you would get a satisfactory answer from our professional technician easily.

4. Free onsite installation and training

If you are able to help us with getting the visa and also would like to bear the costs involved like flight tickets, food, etc, we can send our technician to your office, and to give you a free installation and training for as long as you know how to operate it

 Factory Show



Assembly and Test









Packing and Loading to Truck









  Printed Samples
